The Sharp GP2Y0D810Z0F is a high-speed digital distance sensor, ideal for fast obstacle detection applications.
With a sampling rate of nearly 400Hz, it acts as a fast, reliable alternative to short-range phototransistors and long-range analog sensors.
High-speed sampling rate of 390Hz for rapid detection.
Output is normally HIGH and drops LOW when an object is detected.
Compact, lightweight, and easy to integrate.
Ideal for break-beam detection, object counting, and obstacle detection.
Includes both straight and right-angle 3-pin male headers for flexible connections.
Supply Voltage: 2.7V – 6.2V
Supply Current: 5mA
Sampling Rate: 390Hz
Sensing Principle: Infrared Signal
Sensor Type: Analog Sensor (Digital Output)
Output Behavior: High (no object detected), Low (object detected)
Included: 3-pin male header & 3-pin right-angle male header
Break-beam sensor systems
Object detection in robotics and automation
Obstacle avoidance in mobile robots
Object counting systems
General-purpose proximity sensing
Product details, specifications, and colors may change from time to time without prior notice depending on batch updates or improvements.
