The TCS3200 Colour Sensor Module is an advanced sensor designed for high-resolution conversion of light intensity into frequency. It operates on a single supply voltage between 2.7V and 5.5V, making it highly versatile and easy to integrate with microcontrollers. This sensor can detect a wide range of colors and output frequency, providing precise color sensing for various applications. With programmable features and a direct digital interface, the TCS3200 is ideal for projects requiring accurate color detection, such as automated sorting systems, RGB color sensing, and more.

Features

• Single-supply operation between 2.7V to 5.5V

• High-resolution light intensity to frequency conversion

• Programmable color and full-scale output frequency

• Digital TTL interface for easy communication with microcontrollers

• Direct connection to digital microcontroller pins without the need for an ADC

• Low-profile surface-mount package

• Best detection range up to 100mm

• S0-S1 for output frequency scaling selection and S2-S3 for photodiode type selection

• OE pin for output frequency enable (active low)

• Supports LED lamp light supplement control

Product Specifications

• Operating Voltage: 3V to 5V DC

• Output: Digital TTL frequency

• Interface: Direct communication with microcontrollers via digital pins

• Best Detection Range: 100mm

• Inputs:

  • S0-S1: Output frequency scaling

  • S2-S3: Photodiode type selection

  • OE Pin: Output frequency enable (active low)

• Power Consumption: Low power consumption in active and power-down modes

• Package: Low-profile surface-mount

Applications

• RGB Color Sensing: Used for detecting and distinguishing colors in automated systems

• Sorting Systems: Automated sorting of items based on color recognition

• Lighting Control Systems: Color sensing for controlling RGB LED lights

• Robotics and Automation: Implementing color-based decision-making in robots and automation systems

• Educational Projects: Perfect for teaching basic color sensing in electronics and microcontroller projects

Disclaimer:
Product details, specifications, and colors may change from time to time without prior notice depending on batch updates or improvements.
