Description:
The ACS712 Current Sensor Module is designed to accurately measure both AC and DC currents up to 30A. It is based on the ACS712 sensor and is commonly used in a variety of applications, including over-current protection circuits, battery chargers, switching mode power supplies, digital watt meters, and programmable current sources. With its low-noise analog signal path and extremely stable output, this module ensures precise current measurements in various electronic systems.
Features:
Current Measurement Range: Up to 30A
Sensitivity: 100mV/A
Supply Voltage: 4.5V to 5.5V DC
Low-noise analog signal path
Stable output offset voltage
Zero magnetic hysteresis
Output voltage proportional to AC/DC current
Bandwidth set via FILTER pin (5 µs output rise time in response to step input current)
2.1 kV RMS minimum isolation voltage between pins 1-4 to pins 5-8
Small footprint: Low-profile SOIC8 package
Applications:
Over-current protection circuits
Battery chargers
Switching mode power supplies
Digital watt meters
Programmable current sources
Disclaimer:
Product details, specifications, and colors may change from time to time without prior notice depending on batch updates or improvements.
