Description:
The 1N5822 is a Schottky barrier rectifier diode designed for high-efficiency, low-voltage applications. It offers a low forward voltage drop and fast switching performance, making it ideal for power supply circuits, DC-DC converters, and protection applications.
Specifications:
Type: Schottky Diode
Forward Current: 3A
Reverse Voltage: 40V
Forward Voltage Drop: ~0.5V
Package: DO-201AD (axial)
Mounting: Through-hole
Reverse Leakage Current: Low
Operating Temperature: up to 150°C
The 1N5822 provides efficient rectification with minimal power loss, ideal for low-voltage high-current circuits
Features:
Low forward voltage drop
High efficiency
Fast switching speed
Low power loss
Reliable performance
Applications:
Power supply rectification
DC-DC converters
Solar charge circuits
Battery protection
Reverse polarity protection
Polarity Identification:
Cathode → Marked with a band
Anode → Opposite side
Important Note:
Not suitable for high-voltage applications
Ensure proper current rating is not exceeded
Use heat management for high current loads
Package Includes:
1 × 1N5822 Schottky Diode
