7486 Quad 2-Input OR Gate IC

In Stock

SKU: R4-D-8-5

7486 Quad 2-Input OR Gate IC

(0) | 0 Reviews | 0 Orders | 0 Wish Listed

₹49.00 (Excluded Tax)

Quantity:

Total price: (Tax : )

Download Data Sheet

Overview
Reviews

Description:

The 7486 is a Quad 2-Input XOR Gate IC containing four independent XOR gates, each with two inputs. An XOR (exclusive OR) gate outputs a high (logic 1) when the number of high inputs is odd. In the case of the 7486, it provides an output of logic 1 when one (and only one) of the inputs is high. If both inputs are the same (both high or both low), the output is logic 0.

This IC is part of the 7400 TTL logic family and is commonly used in applications that require logical comparisons, such as in arithmetic circuits, parity generators, and error detection.

Features:

Quad 2-Input XOR Gates: Four independent XOR gates, each with two inputs.
TTL-Compatible Logic: Compatible with standard TTL logic voltage levels.
Fast Switching Times: Ensures high-speed performance in digital circuits.
Low Power Consumption: Designed for energy-efficient applications.
Versatile Use: Ideal for use in comparison circuits, parity checking, and binary addition.

Applications:

Arithmetic and Binary Operations: Used in circuits that perform addition or subtraction.
Parity Checkers: Suitable for error detection in data transmission.
Data Comparisons: Ideal for comparing two data streams or values.
Digital Logic Circuits: Useful in various combinatorial logic designs.
