The 74154 is a 16-line to 4-line decoder IC designed for decoding a 4-bit binary input into a specific one-of-sixteen output. The IC provides a unique logic high output corresponding to the binary input, making it suitable for applications where multiple outputs need to be activated based on binary code.
This decoder IC features active low outputs, which means that one of the 16 output lines will be low (active) based on the 4-bit binary input, while the other outputs will remain high (inactive). It’s ideal for applications such as address decoding, memory selection, and other control functions that require binary-to-line decoding.
4-bit Binary to 16-line Decoding: Decodes a 4-bit binary input into one of 16 active low outputs.
Active Low Outputs: Only one output is active at a time, with all other outputs inactive.
Fast Propagation Delay: Provides fast response for decoding applications.
TTL Logic Compatible: Easily integrates into TTL logic circuits.
Low Power Consumption: Efficient for low-power applications.
Address Decoding: Used in memory addressing and microprocessor systems.
Control Systems: Suitable for control applications where specific outputs need to be selected based on input conditions.
Digital Logic Circuits: Applied in digital systems requiring binary-to-line decoding.
Multiplexing: Can be used in systems that require multiplexing of data lines.
1 x 74154 Decoder IC (DIP-16 Package)
