The LM7812 is a fixed +12V positive voltage regulator from the well-known 78xx series. This three-pin TO-220 package IC is widely used to maintain a stable +12V supply for various electronic components and circuits. It includes thermal overload protection, short circuit protection, and safe operating area protection, making it robust and reliable for both commercial and hobbyist applications.
While designed primarily for fixed voltage output, it can be modified with external components to provide adjustable voltages or currents. With proper heat sinking, it can supply up to 1.5A of output current.
Fixed +12V Positive Output
Output Current: Up to 1.5A
Three-pin configuration
Internal Thermal Overload Protection
Short Circuit Protection
Available in TO-220 Package
Thermal Resistance Junction-to-Case (TO-220): Specified by manufacturer
Thermal Resistance Junction-to-Air (TO-220): Specified by manufacturer
Operating Temperature Range: -40°C to +125°C
| Parameter | Value |
|---|---|
| Output Voltage | +12V |
| Output Current | Up to 1.5A |
| Protection Features | Thermal, Short Circuit |
| Package Type | TO-220 |
| Operating Temperature Range | -40°C to +125°C |
Embedded system power supply
Analog and digital circuit regulation
Consumer electronics
DIY electronics and hobby projects
Local on-board voltage regulation
