Description:
The BC140 is a general-purpose NPN transistor designed for use in medium power applications. It is commonly used in switching and amplification circuits. With a collector-emitter voltage of 80V and a maximum collector current of 1.5A, this transistor is suitable for low to medium power applications. Its compact TO-92 package and high thermal resistance ensure reliable performance in a variety of environments.
Collector-Base Voltage (VCBO): -80V, providing excellent voltage handling capability.
Collector-Emitter Voltage (VCEO): -80V, ensuring stability under high voltage conditions.
Emitter-Base Voltage (VEBO): -5V, ideal for low-voltage circuits.
Collector Current (IC): -1.5A, supporting moderate current loads for various applications.
Junction Temperature (Tj): 150°C, allowing for use in high-temperature environments.
Storage Temperature Range (Tstg): -65°C to 150°C, ensuring reliability over a wide range of environmental conditions.
Thermal Resistance (RθJA): 200°C/W, providing good heat dissipation for efficient operation.
Switching Applications: Ideal for low to medium power switching circuits.
Amplification Circuits: Can be used in audio or signal amplification.
General-Purpose Use: Suitable for a variety of electronic circuits where medium power handling is required.
5x BC140 NPN Transistors.
1x Heatsink compound (for thermal management).
5x Heatsinks (for heat dissipation).
5x Screws (for secure mounting).
Disclaimer: The image provided is solely intended for illustrative purposes, and it's important to note that the brand name and colour may change. This allows for flexibility in adapting to evolving market trends and consumer preferences. Please refer to the specific product details for accurate information.
